Model Kenmore 417.94702300 DRYER – Common Parts &amp; Diagrams

1

Cap,agitator ,standard,slim WCI 3204395 No Longer Available

1

Stud,agitator cap WCI 131206800 Contact Us For Availability

1#

131062300 Frigidaire Timer Backorder WCI 131062300 $172.58

2

Seal,agitator cap WCI 3204396 Contact Us For Availability

3

131398303 Frigidaire Tub Ring Backorder WCI 131398303 $153.02

3

131883301 Frigidaire Panel In Stock WCI 131883301 $165.61

3#

Wiring Harness,dryer control WCI 131484100 Contact Us For Availability

3*

131901400 Frigidaire Seal Backorder WCI 131901400 $13.59

3A

134075500 Frigidaire Lid Bumper Backorder WCI 134075500 $10.87

4

131362400 Frigidaire Fastener In Stock WCI 131362400 $5.88

4

134044501 Frigidaire Rotary Knob In Stock WCI 134044501 $37.19

4#

131212301 Frigidaire Washer Capacitor Motor In Stock WCI 131212301 $6.79

5

5303281019 Frigidaire Ball Assembly Backorder WCI 5303281019 $10.39

5

Grommet,hinge WCI 5303208743 Contact Us For Availability

6

5303212872 Frigidaire Lid Assembly Backorder WCI 5303212872 $200.44

6

5303281020 Frigidaire Ball Clip In Stock WCI 5303281020 $10.85

6

Screw,hex washer head ,1/4-20 x 0.437 WCI 134197900 Contact Us For Availability

7

5303161296 Frigidaire Washer Inlet Hose (1 Pi Backorder WCI 5303161296 $1,678.32

8

Screw,pan head ,6-18AB x 0.60 WCI 3205245 Contact Us For Availability

8#

Timer,washer WCI 134237200 Contact Us For Availability

9

131390000 Frigidaire Door Catch-Strike In Stock WCI 131390000 $34.58

11

3204368 Frigidaire Strike Screw Backorder WCI 3204368 $8.14

12

131476300 Frigidaire Dryer Blower Wheel In Stock WCI 131476300 $29.45

12

131825900 Frigidaire Dryer Rear Drum Bearing In Stock WCI 131825900 $2.81

13

131724301 Frigidaire Dryer Drum Bearing Brack In Stock WCI 131724301 $8.14

13

137546400 Frigidaire Screw 5/16-18 x 0.625 In Stock WCI 137546400 $18.10

13

Resistor,3 kilohm WCI 3205877 Contact Us For Availability

14

131205400 Frigidaire Screw Backorder WCI 131205400 $8.15

14#

Thermostat,heater WCI 131658100 Contact Us For Availability

15#

3204307 Frigidaire Dryer Thermostat Control, Backorder WCI 3204307 $84.16

16

134178901 Frigidaire Screw Backorder WCI 134178901 $9.50

16

Trunnion WCI 131545101 Contact Us For Availability

17

3204254 Frigidaire Baffle Assembly Backorder WCI 3204254 $81.58

131168200 Frigidaire Dryer Screw In Stock WCI 131168200 $9.04

Tub,splash ,w/air dome,brg WCI 131557201 Contact Us For Availability

Cradle,motor mount ,with idler stud WCI 131413600 Contact Us For Availability

Panel,trimplate ,console front WCI 134262000 Contact Us For Availability

20

3204374 Frigidaire Pin Backorder WCI 3204374 $49.74

20

3205150 Frigidaire Tub Bearing Screw Backorder WCI 3205150 $2.26

20

End Cap,white ,LH WCI 131288101 Contact Us For Availability

21

131873304 Frigidaire Dryer Timer Knob White In Stock WCI 131873304 $37.65

21

5308002401 Frigidaire Washer Primary In Stock WCI 5308002401 $10.02

21

Drum,dryer ,painted ,service kit WCI 134122572 Contact Us For Availability

21A

Knob,washer timer ,white/gray WCI 131977101 Contact Us For Availability

3205241 Frigidaire Idler Spring Backorder WCI 3205241 $47.97

Leg & Dome Assy WCI 131373610 Contact Us For Availability

Panel,front ,white ,svce kit w/plug WCI 134031600 Contact Us For Availability

Screw,switch mtg ,6-32 x 0 .19 ,(2), sems WCI 3161259 Contact Us For Availability

23

5304507499 Frigidaire Washer Idler Pulley In Stock WCI 5304507499 $26.74

23#

Wiring Harness,main WCI 134119400 Contact Us For Availability

23*

Screw,terminal block ,(3) WCI 5303208586 No Longer Available

23*

Insert,spring adjuster ,vertical WCI 5303212877 Contact Us For Availability

24

Spring,horizontal WCI 131373900 Contact Us For Availability

25

131658800 Frigidaire Dryer Door Catch Repair In Stock WCI 131658800 $39.43

25

Indicator,timer pointer ,white/gray, washer WCI 131976901 Contact Us For Availability

26#

3204405 Frigidaire Outer Tub Spin Bearing Backorder WCI 3204405 $61.84

26#

Seal Assy,tub ,transmission WCI 5303279394 Contact Us For Availability

27

134242400 Frigidaire Washer Clamp Assembly In Stock WCI 134242400 $11.76

27

5304516871 Frigidaire Replacement Filters Lin In Stock WCI 5304516871 $16.78

28

131784400 Frigidaire Spacer Transmission Bear Backorder WCI 131784400 $30.43

28

Clip,guide ,(3) WCI 5303281074 Contact Us For Availability

28#

134196602 Frigidaire Washer Dryer Motor In Stock WCI 134196602 $153.02

29

131382300 Frigidaire Vane Screw Backorder WCI 131382300 $8.58

29#

Pulley,xmsn drive WCI 131498301 Contact Us For Availability

30#

Idler Arm Assy,VAW ,with pulley WCI 131862900 Contact Us For Availability

31

131202300 Frigidaire Screw Backorder WCI 131202300 $8.60

31

End Cap,white ,RH WCI 131288211 Contact Us For Availability

32

131777700 Frigidaire Dryer Bearing Drum In Stock WCI 131777700 $58.71

33

Spring,torsional WCI 3204425 Contact Us For Availability

33#

134211400 Frigidaire Valve Primary In Stock WCI 134211400 $44.83

33#

3204267 Frigidaire Dryer Safety Thermostat In Stock WCI 3204267 $34.85

34

131205500 Frigidaire Screw Backorder WCI 131205500 $8.60

34

131243800 Frigidaire Screw Backorder WCI 131243800 $6.53

35

131892100 Frigidaire Screw Backorder WCI 131892100 $6.32

35

3161433 Frigidaire Retainer Backorder WCI 3161433 $11.76

35

Snubber Ring WCI 5308002385 Contact Us For Availability

36

Washer,pivot shaft WCI 5303261031 Contact Us For Availability

36#

134120900 Frigidaire Dryer Limiter Thermal In Stock WCI 134120900 $3.43

37

Washer,spring type WCI 5303161306 Contact Us For Availability

38

Nut,hex flange ,motor mounting WCI 5303318708 Contact Us For Availability

38

Base Assembly WCI 5303311213 Contact Us For Availability

38#

Buzzer WCI 5303286537 Contact Us For Availability

39

131205100 Frigidaire Screw In Stock WCI 131205100 $9.06

40#

134159500 Frigidaire Washer Main Drive Motor In Stock WCI 134159500 $273.60

41

131513300 Frigidaire Shield Backorder WCI 131513300 $54.76

42

Panel,front ,white WCI 131104303 Contact Us For Availability

43

Pad,leveling leg ,front WCI 131422100 Contact Us For Availability

43A

131422200 Frigidaire P-1 Self Level Leg Pad In Stock WCI 131422200 $36.24

44

134548800 Frigidaire Washer Leg Levelling In Stock WCI 134548800 $9.04

44

137551901 Frigidaire Gasket Backorder WCI 137551901 $24.94

45

Pin,panel locator ,side WCI 131346400 Contact Us For Availability

45*

131453000 Frigidaire Bushing Backorder WCI 131453000 $6.80

45*

Cushion,drain hose ,base WCI 131663500 Contact Us For Availability

45A

131346401 Frigidaire Pin Backorder WCI 131346401 $10.41

46

131789400 Frigidaire Handle In Stock WCI 131789400 $46.47

48

5304536802 Frigidaire Hose Clamp Backorder WCI 5304536802 $2.42

48

Panel,outer door ,white WCI 131789303 Contact Us For Availability

49#

131494800 Frigidaire Hose-Pump P1 to Tub In Stock WCI 131494800 $45.70

50#

Lock,lid ,w/ext switch WCI 134101800 Contact Us For Availability

53

5304401845 Frigidaire Pressure Tube Backorder WCI 5304401845 $36.74

54

Dispenser,bleach WCI 3204394 Contact Us For Availability

54#

Wiring Harness,door switch ,w/o light WCI 131498900 Contact Us For Availability

58

134160900 Frigidaire Screw Backorder WCI 134160900 $7.69

68

131707800 Frigidaire Drain Hose Ring Backorder WCI 131707800 $28.33

68*

5303309503 Frigidaire Clip Assembly Backorder WCI 5303309503 $4.53
