Model LG 32UD99-W – Common Parts & Diagrams
Diagram 0
Diagram 1
Common parts from model LG 32UD99-W
121
Speaker Assembly LGE EAB64488802 Contact Us For Availability
200
LCD,Module-TFT LGE EAJ64451501 Contact Us For Availability
200
LCD,Module-TFT LGE EAJ64007801 Contact Us For Availability
200
LCD,Module-TFT LGE EAJ64248801 Contact Us For Availability
200T
Time Control LGE EAT64113101 Contact Us For Availability
300
Cabinet Assembly LGE ABJ75427601 Contact Us For Availability
330
PCB Assembly,Sub LGE EBR81120012 Contact Us For Availability
400
Cover Assembly,Rear LGE ACQ89276902 Contact Us For Availability
500
Main Board,BPR Total Assembly LGE EBU63785302 Contact Us For Availability
510
Frame Assembly LGE ADV76067102 Contact Us For Availability
900
Base Assembly LGE AAN75928701 Contact Us For Availability
910
Base Assembly LGE AAN75869001 Contact Us For Availability
A1
Manual Assembly LGE AFN77734721 Contact Us For Availability
A7
Card LGE 3840TWL061C Contact Us For Availability
A10
Card LGE MBM65364019 Contact Us For Availability
A11
Card LGE 3840TRL039A Contact Us For Availability
A13
Cable,Assembly LGE EAD63127604 Contact Us For Availability
C10
Harness,Single LGE EAD63990401 Contact Us For Availability
C107
Resistor,Chip LGE 0RJ0000C678 Contact Us For Availability
C514
Capacitor,Ceramic,Chip LGE 0CC225EKFBA Contact Us For Availability
C543
CAPACITOR,FIXED CERA LGE 0CK105CK56A Contact Us For Availability
C611
Capacitor,Ceramic,Chip LGE EAE33831901 Contact Us For Availability
C806
Capacitor,Ceramic,Chip LGE EAE59211001 Contact Us For Availability
C830
CAPACITOR,FIXED CERA LGE 0CK105CD56A Contact Us For Availability
C845
Capacitor,Ceramic,Chip LGE EAE52158501 Contact Us For Availability
C848
Capacitor,Ceramic,Ch LGE 0CK104BF56A Contact Us For Availability
C857
Capacitor,Ceramic,Chip LGE EAE60663801 Contact Us For Availability
C858
Capacitor,Ceramic,Ch LGE 0CK104BH56A Contact Us For Availability
C870
Capacitor,Ceramic,Chip LGE EAE60364701 Contact Us For Availability
C1015
CAPACITOR,FIXED CERA LGE 0CK104CK56A Contact Us For Availability
IC1000
IC,DC,DC Converter LGE EAN62794401 Contact Us For Availability
L306
Filter,Bead LGE EAM32500208 Contact Us For Availability
LV1
Cable,FFC LGE EAD63825214 Contact Us For Availability
MT1
Tape,Double Faced LGE RAB34873121 Contact Us For Availability
Q502
FET LGE EBK61913702 Contact Us For Availability
R302
Resistor,Chip LGE 0RJ0222C678 Contact Us For Availability
R313
Resistor,Chip LGE 0RJ1001E478 Contact Us For Availability
R537
Resistor,Chip LGE 0RJ4701C678 Contact Us For Availability
R603
Resistor,Chip LGE 0RJ3301C478 Contact Us For Availability
R605
Resistor,Chip LGE 0RJ2402C478 Contact Us For Availability
R608
Resistor,Chip LGE 0RJ2203C478 Contact Us For Availability
R626
Resistor,Chip LGE 0RJ4701C478 Contact Us For Availability
R645
RESISTOR,METAL GLAZE LGE 0RJ5101C478 Contact Us For Availability
R646
Resistor,Chip LGE 0RJ5102C678 Contact Us For Availability
R652
Resistor,Chip LGE 0RJ1003C678 Contact Us For Availability
R708
Resistor,Chip LGE 0RJ1001C678 Contact Us For Availability
R712
Resistor,Chip LGE 0RJ6201C478 Contact Us For Availability
R713
Resistor,Chip LGE 0RJ2003C478 Contact Us For Availability
R833
Resistor,Chip LGE 0RJ1203C478 Contact Us For Availability
R840
Resistor,Chip LGE 0RJ1002C678 Contact Us For Availability
R841
Resistor,Chip LGE 0RJ5601C478 Contact Us For Availability
R870
Resistor,Chip LGE 0RJ0332C678 Contact Us For Availability
R1002
Resistor,Chip LGE 0RJ7502C478 Contact Us For Availability
R1016
RESISTOR,METAL GLAZE LGE 0RJ2002C478 Contact Us For Availability
VR502
Varistor LGE EAF61630102 Contact Us For Availability
ZD1003
Diode,TVS LGE EAH62134701 Contact Us For Availability
× ![]()
