Model LG 32MN60T-B – Common Parts & Diagrams
Diagram 0
Diagram 1
Common parts from model LG 32MN60T-B
300
Cabinet Assembly LGE ABJ76207102 Contact Us For Availability
400
Cover Assembly,Rear LGE ACQ90777708 Contact Us For Availability
500
Main Board,BPR Total Assembly LGE EBU66080403 Contact Us For Availability
510
Frame Assembly LGE ADV77146101 Contact Us For Availability
520
Plate,Metal LGE MGJ66342403 Contact Us For Availability
530
Bracket Assembly LGE ABA76589102 Contact Us For Availability
930
Package Assembly LGE AGF76702601 Contact Us For Availability
A4
Card LGE MBM67239272 Contact Us For Availability
A7
Card LGE 3840TWL061C Contact Us For Availability
A8
Cable,Assembly LGE EAD63954401 Contact Us For Availability
A9
Card LGE 3840TRL039A Contact Us For Availability
C125
Capacitor,Ceramic,Ch LGE 0CK104BF56A Contact Us For Availability
C447
CAPACITOR,FIXED CERA LGE 0CK104CK56A Contact Us For Availability
C461
CAPACITOR,FIXED CERA LGE 0CK105CK56A Contact Us For Availability
C468
Capacitor,Ceramic,Ch LGE 0CK474DK56A Contact Us For Availability
P402
Connector,Wafer LGE EAG62172203 Contact Us For Availability
R115
Resistor,Chip LGE 0RJ4701C678 Contact Us For Availability
R128
Resistor,Chip LGE 0RJ0332C678 Contact Us For Availability
R252
Resistor,Chip LGE 0RJ0000C678 Contact Us For Availability
R474
Resistor,Chip LGE 0RJ1002C678 Contact Us For Availability
R477
Resistor,Chip LGE 0RJ1003C678 Contact Us For Availability
R479
Resistor,Chip LGE 0RJ1001C678 Contact Us For Availability
R485
Resistor,Chip LGE 0RJ0100J488 Contact Us For Availability
× ![]()
