Model Electrolux 30-3858-23-03 RANGE – Common Parts &amp; Diagrams

*26442

SHIELD, BI METAL LATCH WCI 3131593 Contact Us For Availability

*26443

SCREW, LATCH KNOB WCI 636T144P01 Contact Us For Availability

*26444

SHIELD HEAT BODYSIDE (2) WCI 3200834 Contact Us For Availability

*26445

3131903 Frigidaire Door/Drawer Bumper Backorder WCI 3131903 $33.06

*26446

FASTENER, POWER CORD WCI 241T017P255 Contact Us For Availability

*26447

INSULATION, BACK WCI 3131303 Contact Us For Availability

*26448

08067973 Frigidaire 0 Insulation Backorder WCI 08067973 $33.06

*26449

INSULATION-TOP WCI 3131304 Contact Us For Availability

*26450

SHIELD, WIRE WCI 655T434F01 Contact Us For Availability

*26451

INSULATION, TOUCH WCI 3131305 Contact Us For Availability

*26453

WCI 657T018P01 WCI 657T018P01 Contact Us For Availability

*26454

INSULATION, WRAP WCI 3200833 Contact Us For Availability

*26457

SPACER, BAFFLE WCI 3131956 Contact Us For Availability

1

WCI 3131962 WCI 3131962 Contact Us For Availability

1

WCI 3131283 WCI 3131283 Contact Us For Availability

1

SPACER, BODYSIDE (8) WCI 665T188P02 Contact Us For Availability

1

WCI 301133 WCI 301133 Contact Us For Availability

2

3051163 Frigidaire Oven Range Rear Broiler Dr In Stock WCI 3051163 $2.37

2

GLASS FRONT, BLACK WCI 276T106P03 Contact Us For Availability

2

KNOB, TOP VALVE (4) WCI 3131581 Contact Us For Availability

2

WCI 3131284 WCI 3131284 Contact Us For Availability

3

HANDLE, OVEN DOOR WCI 3131256 Contact Us For Availability

3

WCI 3934004 WCI 3934004 Contact Us For Availability

3

WCI 079T028P01 WCI 079T028P01 Contact Us For Availability

3

WCI 3131363 WCI 3131363 Contact Us For Availability

3

WCI 3131184 WCI 3131184 Contact Us For Availability

4

316035200 Frigidaire Ignition Switch In Stock WCI 316035200 $57.35

4

316116400 Frigidaire Oven Light Socket In Stock WCI 316116400 $40.25

4

WCI 3201692 WCI 3201692 Contact Us For Availability

4

ROD, MAIN TOP SUPPORT (2) WCI 618T038P05 Contact Us For Availability

4

WCI 3131290 WCI 3131290 Contact Us For Availability

5

316538904 Frigidaire Oven Light Lamp In Stock WCI 316538904 $10.61

5

5303131601 Frigidaire Oven Seal Backorder WCI 5303131601 $203.31

5

BRACKET, MAIN TOP, HINGE, LEFT HAND WCI 3011558 Contact Us For Availability

5

WCI 079T032S02 WCI 079T032S02 Contact Us For Availability

5

WCI 3131975 WCI 3131975 Contact Us For Availability

6

WCI 3131436 WCI 3131436 Contact Us For Availability

6

WCI 3201693 WCI 3201693 Contact Us For Availability

6

BRACKET, MAIN TOP, HINGE, RIGHT HAND WCI 3011559 Contact Us For Availability

6

WCI 3018617 WCI 3018617 Contact Us For Availability

6

WCI 3131104 WCI 3131104 Contact Us For Availability

6

FASTENER-SPACER (2) WCI 3131387 Contact Us For Availability

6A

SCREW, PANEL ASSEMBLY (2) (NON-ILLUSTRATED) WCI 636T162P01 Contact Us For Availability

6B

5303300265 Frigidaire Oven Screw Backorder WCI 5303300265 $9.04

7

5303131115 Frigidaire Range Chrome Drip Bowl, In Stock WCI 5303131115 $5.64

7

FLUORESCENT BRACKET, LEFT HAND WCI 3131576 Contact Us For Availability

7

SUPPORT, GLASS WCI 3131323 Contact Us For Availability

7

BURNER TUBE, LEFT FRONT, RIGHT FRONT WCI 3131970 Contact Us For Availability

7

GLASS, OVEN LAMP WCI 3131298 Contact Us For Availability

8

316055800 Frigidaire Oven Grate In Stock WCI 316055800 $26.27

8

FLUORESCENT BRACKET, RIGHT HAND WCI 3131577 Contact Us For Availability

8

WCI 3934033 WCI 3934033 Contact Us For Availability

8

WCI 079T033H02 WCI 079T033H02 Contact Us For Availability

8

CHANNEL-DOOR HINGE WCI 3131569 Contact Us For Availability

8A

RETAINER, WIRE (NON-ILLUSTRATED) WCI 612T124P01 Contact Us For Availability

9

COVER-HINGE CUTOUT (2) WCI 3131570 Contact Us For Availability

9

RECEPTACLE, FLUORESCENT LIGHT, LEFT HAND WCI 3051222 Contact Us For Availability

9

WCI 3051728 WCI 3051728 Contact Us For Availability

9

WCI 079T033H03 WCI 079T033H03 Contact Us For Availability

10

RECEPTACLE, FLUORESCENT LIGHT, RIGHT HAND WCI 3051223 Contact Us For Availability

10

CLIP, RETAINER (2) WCI 3131720 Contact Us For Availability

10

WCI 3131312 WCI 3131312 Contact Us For Availability

LAMP, BULB, FLUORESCENT WCI 3131275 Contact Us For Availability

FASTENER, NYLON (6) WCI 3131974 Contact Us For Availability

WCI 247T074P01 WCI 247T074P01 Contact Us For Availability

WCI 3131313 WCI 3131313 Contact Us For Availability

PANEL, SPLASHER WCI 3131965 Contact Us For Availability

SCREW, HANDLE (2) WCI 3131102 Contact Us For Availability

WCI 3131105 WCI 3131105 Contact Us For Availability

CLIP, THERMOSTAT BULB (2) WCI 3131295 Contact Us For Availability

WCI 3131241 WCI 3131241 Contact Us For Availability

FASTENER, NYLON SPACER (3) WCI 241T017P185 Contact Us For Availability

MANIFOLD, PIPE WCI 439T055P03 Contact Us For Availability

WCI 3051734 WCI 3051734 Contact Us For Availability

FASTENER, GLASS (2) WCI 3131607 Contact Us For Availability

INSULATION, OVEN DOOR WCI 3131384 Contact Us For Availability

VALVE, 3 POSITION (4) WCI 3017846 Contact Us For Availability

FASTENER, PUSH ON (3) WCI 241T001P01 Contact Us For Availability

14A

STUD, SPACER (2) (NON-ILLUSTRATED) WCI 3051307 Contact Us For Availability

15

WCI 045T071P01 WCI 045T071P01 Contact Us For Availability

15

WCI 215T013P01 WCI 215T013P01 Contact Us For Availability

15

WCI 174T329P01 WCI 174T329P01 Contact Us For Availability

15A

NUT, COMPRESSION (4) (NON-ILLUSTRATED) WCI 3131148 Contact Us For Availability

16

NUT, DECORATIVE (2) WCI 3051194 Contact Us For Availability

16

WCI 3131567 WCI 3131567 Contact Us For Availability

17

5303935068 Frigidaire Flat Igniter In Stock WCI 5303935068 $89.52

17

KNOB, CLOCK (3) WCI 358T206P01 Contact Us For Availability

17

WCI 3051495 WCI 3051495 Contact Us For Availability

18

5303935066 Frigidaire Oven Flat Igniter 17-In In Stock WCI 5303935066 $23.65

18

SWITCH, FLUORESCENT LIGHT WCI 3051312 Contact Us For Availability

18

ANGLE, LIGHT SHIELD WCI 3131278 Contact Us For Availability

19

5304505695 Frigidaire Oven Module In Stock WCI 5304505695 $40.27

19

WCI 3131145 WCI 3131145 Contact Us For Availability

19

CHANNEL, LIGHT SHIELD WCI 3131294 Contact Us For Availability

20

WCI 3051115 WCI 3051115 Contact Us For Availability

20

WCI 455T008P02 WCI 455T008P02 Contact Us For Availability

20

WCI 695T128P04 WCI 695T128P04 Contact Us For Availability

21

CAP, LEFT HAND WCI 123T120P03 Contact Us For Availability

21

HEX NUT WCI 3131358 Contact Us For Availability

21

BRACKET, LIGHT SWITCH WCI 3131289 Contact Us For Availability

22

CAP, RIGHT HAND WCI 123T120P04 Contact Us For Availability

22

SHIELD, REAR WALL WCI 3131590 Contact Us For Availability

23

SHIELD, BACKGUARD WCI 3131123 Contact Us For Availability

23

WCI 3131316 WCI 3131316 Contact Us For Availability

24

SHIELD, FLUORESCENT LIGHT WCI 3131137 Contact Us For Availability

24

CLIP, WIRE WCI 145T130P01 Contact Us For Availability

25

ANGLE, SELF-CONTAINED THERMOSTAT MOUNTING WCI 3131467 Contact Us For Availability

25

FITTING, LOXIT (6) WCI 3131261 Contact Us For Availability

25

WCI 3131931 WCI 3131931 Contact Us For Availability

26

316542102 Frigidaire Flue Gasket Backorder WCI 316542102 $7.23

26

THERMOSTAT, OVEN, SELF-CONTAINED WCI 722T071P01 Contact Us For Availability

27

WCI 2121964 WCI 2121964 Contact Us For Availability

27

TUBE, ALUMINUM, 3/8 WCI 750T085H09 Contact Us For Availability

27

WCI 358T158S02 WCI 358T158S02 Contact Us For Availability

27A

WASHER, BLACK (NON-ILLUSTRATED) WCI 3131737 Contact Us For Availability

27B

WCI 655T437F01 WCI 655T437F01 Contact Us For Availability

28

SWITCH, SELECTOR WCI 3091345 Contact Us For Availability

28

TUBE, ALUMINUM, 3/8 WCI 3131109 Contact Us For Availability

28

WCI 368T027P01 WCI 368T027P01 Contact Us For Availability

29

KNOB, SELECTOR SWITCH WCI 3131724 Contact Us For Availability

29

TUBE, ALUMINUM, VALVE/MIXED WCI 3131364 Contact Us For Availability

29

WCI 3131357 WCI 3131357 Contact Us For Availability

29A

FASTENER-EDGE MOUNT (2) (NON-ILLUSTRATED) WCI 3200846 Contact Us For Availability

30

5303208499 Frigidaire Gas Safety Valve In Stock WCI 5303208499 $359.54

30

KNOB, THERMOSTAT WCI 3131725 Contact Us For Availability

30

WCI 3131101 WCI 3131101 Contact Us For Availability

30A

5300809968 Frigidaire Dishwasher P-1 Washer Backorder WCI 5300809968 $27.18

31

WCI 095T030F02-86 WCI 095T030F02-86 Contact Us For Availability

32

5303935125 Frigidaire Pressure Regulator Backorder WCI 5303935125 $256.42

32

SHIELD, MAIN FRONT WCI 3200835 Contact Us For Availability

33

316091600 Frigidaire Oven Bracket Backorder WCI 316091600 $43.49

33

WCI 3131314 WCI 3131314 Contact Us For Availability

34

5303013272 Frigidaire Oven Nut Backorder WCI 5303013272 $0.28

34

WCI 3200836 WCI 3200836 Contact Us For Availability

35

SPUD, NUMBER 50 WCI 499T015P08 Contact Us For Availability

35

PANEL, BODYSIDE, ALMOND (RIGHT HAND) WCI 3200790 Contact Us For Availability

35A

PANEL ,BODYSIDE, ALMOND (LEFT HAND) WCI 3200793 Contact Us For Availability

36

WCI 479T069P40 WCI 479T069P40 Contact Us For Availability

36

WCI 636M004P01 WCI 636M004P01 Contact Us For Availability

37

316067902 Frigidaire Oven Rack Backorder WCI 316067902 $65.19

37

WCI 136T355W03 WCI 136T355W03 Contact Us For Availability

38

WCI 3131356 WCI 3131356 Contact Us For Availability

39

PAN, BROILER WCI 539T010F01-86 Contact Us For Availability

40

WCI 058T036F03-86 WCI 058T036F03-86 Contact Us For Availability

40A

316064600 Frigidaire Oven Support Backorder WCI 316064600 $11.32

41

BUTTON, REMOVE SWITCH WCI 102T044P02 Contact Us For Availability

42

COVER, BURNER BOX WCI 174T333P01 Contact Us For Availability

43

3051162 Frigidaire Oven Range Front Broiler D In Stock WCI 3051162 $1.76

44

316282700 Frigidaire Oven Screw Backorder WCI 316282700 $6.32
