Model Electrolux 30-3648-00-03 RANGE – Common Parts &amp; Diagrams

*42658

INSULATION-OVEN WRAP WCI 3017142 Contact Us For Availability

*42658

INSULATION-BACK WCI 3203541 Contact Us For Availability

3131903 Frigidaire Door/Drawer Bumper Backorder WCI 3131903 $32.52

316064600 Frigidaire Oven Support Backorder WCI 316064600 $11.13

WCI 08067961 WCI 08067961 Contact Us For Availability

PLATE-OVEN LIGHT WCI 3018615 Contact Us For Availability

WCI 3131244 WCI 3131244 Contact Us For Availability

WCI 5303015372 WCI 5303015372 Contact Us For Availability

*42660

316282700 Frigidaire Oven Screw Backorder WCI 316282700 $6.22

*42660

WCI 191F018F255 WCI 191F018F255 Contact Us For Availability

*42660

WCI 3015371 WCI 3015371 Contact Us For Availability

1

316091600 Frigidaire Oven Bracket Backorder WCI 316091600 $42.77

1

SPACER WCI 3014099 Contact Us For Availability

1

WCI 5303131937 WCI 5303131937 Contact Us For Availability

1

BRKT-BROIL HINGE-LH WCI 3200673 Contact Us For Availability

1

WCI 5303209518 WCI 5303209518 Contact Us For Availability

1A

BRKT-BROIL HINGE-RH WCI 3018860 Contact Us For Availability

2

5303935125 Frigidaire Pressure Regulator Backorder WCI 5303935125 $251.84

2

WCI 5303201082 WCI 5303201082 Contact Us For Availability

2

FSTNR - PUSH NUT WCI 3131386 Contact Us For Availability

2

HANDLE WCI 5303131256 Contact Us For Availability

3

316116400 Frigidaire Oven Light Socket In Stock WCI 316116400 $36.58

3

WCI 3201081 WCI 3201081 Contact Us For Availability

3

WCI 3018608 WCI 3018608 Contact Us For Availability

3

GLASS-FRONT, BLACK WCI 3051152 Contact Us For Availability

3

WCI 5303014477 WCI 5303014477 Contact Us For Availability

4

316538904 Frigidaire Oven Light Lamp In Stock WCI 316538904 $10.44

4

3203459 Frigidaire Oven Range Dual Gas Safety In Stock WCI 3203459 $169.78

4

PANEL-MAIN TOP-WHITE WCI 3934003 Contact Us For Availability

4

PIN, HINGE (2) WCI 3018614 Contact Us For Availability

4

WCI 3131720 WCI 3131720 Contact Us For Availability

5

ROD-MAIN TOP SUPT. (2) WCI 3013818 Contact Us For Availability

5

SPRING-BROIL-LH-C TYPE WCI 3018618 Contact Us For Availability

5

WCI 3202148 WCI 3202148 Contact Us For Availability

5

BRKT, OVEN BURNER SUPT WCI 3018603 Contact Us For Availability

5

CHANNEL-DOOR HINGE (2) WCI 5303131569 Contact Us For Availability

5A

SPRING-BROIL-RH-C TYPE WCI 3018619 Contact Us For Availability

6

COVER-HINGE CUTOUT (2) WCI 3131570 Contact Us For Availability

6

BRKT-MAIN TOP HINGE LH WCI 08067746 Contact Us For Availability

6

WCI 3131439 WCI 3131439 Contact Us For Availability

6

LINER-BROIL DRWR WCI 3202803 Contact Us For Availability

6

INSULATION - OVEN DOOR WCI 3200528 Contact Us For Availability

7

BRKT-MAIN TOP HINGE RH WCI 08067747 Contact Us For Availability

7

PNL BROIL-WHITE WCI 3131117 Contact Us For Availability

7

GLASS-OVEN DOOR (REAR) WCI 3018609 Contact Us For Availability

7

TUBE-ALUM VALVE/REGUL WCI 3131448 Contact Us For Availability

7

WCI 3203082 WCI 3203082 Contact Us For Availability

8

5303131115 Frigidaire Range Chrome Drip Bowl, In Stock WCI 5303131115 $5.55

8

5303912606 Frigidaire Oven Range Spark Module In Stock WCI 5303912606 $81.46

8

WCI 3131125 WCI 3131125 Contact Us For Availability

8

WCI 3131323 WCI 3131323 Contact Us For Availability

8

WCI 3131660 WCI 3131660 Contact Us For Availability

9

316055800 Frigidaire Oven Grate Backorder WCI 316055800 $25.85

9

FSTNR, SPACER (2) WCI 3131387 Contact Us For Availability

9

WCI 3931014 WCI 3931014 Contact Us For Availability

9

CLIP-WIRE WCI 3011813 Contact Us For Availability

5303013272 Frigidaire Oven Nut Backorder WCI 5303013272 $11.11

LAMP BULB FLUOR. WCI 3131275 Contact Us For Availability

WCI 3018610 WCI 3018610 Contact Us For Availability

SCREW, HANDLE (2) WCI 3016851 Contact Us For Availability

WCI 3131904 WCI 3131904 Contact Us For Availability

316542102 Frigidaire Flue Gasket Backorder WCI 316542102 $7.11

WCI 5303131356 WCI 5303131356 Contact Us For Availability

WCI 5303015373 WCI 5303015373 Contact Us For Availability

WCI 3203265 WCI 3203265 Contact Us For Availability

12

PAN-BROILER WCI 5303013568 Contact Us For Availability

12

FSTNR-SPACER (3) WCI 5303131254 Contact Us For Availability

12

WCI 08067757 WCI 08067757 Contact Us For Availability

12A

INSULATION-BROILER DRWR (NON-ILLUSTRATED) WCI 5303131258 Contact Us For Availability

12C

SCREW (2) (NON-ILLUSTRATED) WCI 3013964 Contact Us For Availability

5303935066 Frigidaire Oven Flat Igniter 17-In In Stock WCI 5303935066 $23.27

WCI 3131153 WCI 3131153 Contact Us For Availability

WCI 3934033 WCI 3934033 Contact Us For Availability

WCI 3011597 WCI 3011597 Contact Us For Availability

WCI 3018607 WCI 3018607 Contact Us For Availability

FSTNR, PUSH IN (6) WCI 3131974 Contact Us For Availability

B/S - PNL - WHITE - RH WCI 5303269518 Contact Us For Availability

WCI 5303269543 WCI 5303269543 Contact Us For Availability

WCI 5303271917 WCI 5303271917 Contact Us For Availability

14A

B/S - PNL - WHITE - LH WCI 5303269519 Contact Us For Availability

14A

WCI 5303269545 WCI 5303269545 Contact Us For Availability

14A

WCI 5303271918 WCI 5303271918 Contact Us For Availability

15

5303202011 Frigidaire Door Seal Backorder WCI 5303202011 $94.33

15

SCREW-LEVELING WCI 5303203397 Contact Us For Availability

15

WCI 5303017931 WCI 5303017931 Contact Us For Availability

15A

SCREW (3) (NON-ILLUSTRATED) WCI 3131573 Contact Us For Availability

15A

WCI 08010570 WCI 08010570 Contact Us For Availability

15B

5303300265 Frigidaire Oven Screw Backorder WCI 5303300265 $8.89

16

316067902 Frigidaire Oven Rack Backorder WCI 316067902 $63.90

16

WCI 3201083 WCI 3201083 Contact Us For Availability

17

KNOB-ELEC CLOCK WCI 5303016292 Contact Us For Availability

17

WCI 5303201080 WCI 5303201080 Contact Us For Availability

17

WCI 5303212540 WCI 5303212540 Contact Us For Availability

18

5303284616 Frigidaire Range Bulb Clip Thermos In Stock WCI 5303284616 $5.78

18

WCI 5303200479 WCI 5303200479 Contact Us For Availability

18

WCI 3203457 WCI 3203457 Contact Us For Availability

19

SWITCH-FLUOR LIGHT WCI 5303200480 Contact Us For Availability

19

WCI 3017932 WCI 3017932 Contact Us For Availability

20

GLASS-WORK LIGHT WCI 3131145 Contact Us For Availability

20

WCI 3017935 WCI 3017935 Contact Us For Availability

20

WCI 3131348 WCI 3131348 Contact Us For Availability

21

WCI 5303051115 WCI 5303051115 Contact Us For Availability

21

WCI 3017933 WCI 3017933 Contact Us For Availability

21

WCI 5303270160 WCI 5303270160 Contact Us For Availability

22

3203010 Frigidaire Clip Backorder WCI 3203010 $9.35

22

WCI 5303018604 WCI 5303018604 Contact Us For Availability

22

WCI 3017934 WCI 3017934 Contact Us For Availability

22A

WCI 3018605 WCI 3018605 Contact Us For Availability

23

SHIELD B/G WCI 3131123 Contact Us For Availability

23

WCI 3013279 WCI 3013279 Contact Us For Availability

24

WCI 3131507 WCI 3131507 Contact Us For Availability

24

WCI 5303131105 WCI 5303131105 Contact Us For Availability

25

WCI 3131919 WCI 3131919 Contact Us For Availability

25

WCI 3206267 WCI 3206267 Contact Us For Availability

26

WCI 5303051347 WCI 5303051347 Contact Us For Availability

26

RETAINER-IGNITION WCI 3018617 Contact Us For Availability

27

BURNER TOP (4) WCI 5303011567 Contact Us For Availability

28

FERRULE (4) WCI 08067945 Contact Us For Availability

29

WCI 3131261 WCI 3131261 Contact Us For Availability

33

NUT COMPRESSION (4) WCI 3131148 Contact Us For Availability

33A

SCREW, VALVE MTG (NON-ILLUSTRATED) WCI 3204499 Contact Us For Availability
