Model LG 26LC2R – Common Parts & Diagrams
Diagram 0
Diagram 1
Common parts from model LG 26LC2R
0
Harness,Single LGE 6631900108C Contact Us For Availability
0
Harness,Single LGE EAD30302101 Contact Us For Availability
0
Indicator LGE 3520900017A Contact Us For Availability
0
BOX LGE 3890TSE750M Contact Us For Availability
0
CONNECTOR ASSEMBLY LGE 6631900048A Contact Us For Availability
0
Harness,Single LGE 6631900050D Contact Us For Availability
0
Harness,Single LGE 6631900060A Contact Us For Availability
0
Screw,Taptite LGE FAB30013601 Contact Us For Availability
0
S/W,Firmware LGE SAA30004218 Contact Us For Availability
0
Harness,Single LGE 6631900018H Contact Us For Availability
0
Screw,Taptite LGE FAB30013608 Contact Us For Availability
0
Screw Assembly LGE FAB30016407 Contact Us For Availability
0
Remote Controller LGE 6710900010W Contact Us For Availability
0
Screw,Taptite LGE FAB30005103 Contact Us For Availability
0
Screw,Taptite LGE FAB30011003 Contact Us For Availability
0
Box LGE 3890900171E Contact Us For Availability
0
POWER CORD LGE 6410TBW004A Contact Us For Availability
0
Harness,Single LGE 6631900049C Contact Us For Availability
0
Screw,Taptite LGE FAB30013213 Contact Us For Availability
0
Bag LGE 38809P0013G Contact Us For Availability
0
CONNECTOR ASSEMBLY LGE 6631T25026C Contact Us For Availability
0
Screw,Taptite LGE FAB30007505 Contact Us For Availability
0
Screw Assembly LGE FAB30007702 Contact Us For Availability
0
Screw,Taptite LGE FAB30013206 Contact Us For Availability
0
Screw,Taptite LGE FAB30013210 Contact Us For Availability
0
Manual LGE 38289U0005H Contact Us For Availability
0
Chassis Assembly LGE 31419SNK07A Contact Us For Availability
0
Cable,Assembly LGE 68509A0004U Contact Us For Availability
0
Screw Assembly LGE FAB30009502 Contact Us For Availability
0
Screw Assembly LGE FAB30012001 Contact Us For Availability
0
Screw,Taptite LGE FAB30018405 Contact Us For Availability
0
Manual LGE 3828TUL306A Contact Us For Availability
0
Packing LGE 3920900169A Contact Us For Availability
0
Harness,Single LGE 6631900012C Contact Us For Availability
010
Cover Assembly LGE 30919E0027A Contact Us For Availability
020
LCD,Module-TFT LGE 6304FAU020B Contact Us For Availability
030
Cover Assembly LGE 3809900134A Contact Us For Availability
040
Base Assembly LGE 3043900029A Contact Us For Availability
050
PCB Assembly,Sub LGE 68719ST934A Contact Us For Availability
060
Plate Assembly LGE 49519S0021B Contact Us For Availability
070
PCB Assembly,Sub LGE 68719STA75A Contact Us For Availability
080
SMPS,AC/DC LGE 6709900016C Contact Us For Availability
090
Main Total Assembly LGE 33139L3028A Contact Us For Availability
100
Plate Assembly LGE 49519S0030B Contact Us For Availability
110
Speaker,Fullrange LGE EAB30827201 Contact Us For Availability
120
PCB Assembly,Sub LGE EBR30373401 Contact Us For Availability
130
Bracket LGE 4810900046A Contact Us For Availability
140
Bracket Assembly LGE 4811900063A Contact Us For Availability
150
COVER LGE 35509K0197A Contact Us For Availability
AR602
RESISTOR,METAL GLAZE LGE 0RJ0222C687 Contact Us For Availability
C160
CAPACITOR,FIXED ELEC LGE 0CE227SF6DC Contact Us For Availability
C172
Capacitor,Ceramic,Chip LGE 0CK682CK51A Contact Us For Availability
C201
Capacitor,Ceramic,Chip LGE 0CH5330K416 Contact Us For Availability
C203
Capacitor,AL,Radial LGE 0CE4763F618 Contact Us For Availability
C301
Capacitor,Ceramic,Chip LGE 0CH5101K416 Contact Us For Availability
C311
Capacitor,Ceramic,Chip LGE 0CC470CK41A Contact Us For Availability
C347
CAPACITOR,FIXED CERA LGE 0CK104CF56A Contact Us For Availability
C429
LGE 0CK822CK46A LGE 0CK822CK46A Contact Us For Availability
C430
CAPACITOR,FIXED CERA LGE 0CK823CF56A Contact Us For Availability
C509
CAPACITOR,FIXED CERA LGE 0CC270CK41A Contact Us For Availability
C514
Capacitor,Ceramic,Chip LGE 0CK273CK56A Contact Us For Availability
C521
CAPACITOR,FIXED CERA LGE 0CC271CK41A Contact Us For Availability
C626
CAPACITOR,FIXED CERA LGE 0CK103CK56A Contact Us For Availability
C632
CAPACITOR,FIXED CERA LGE 0CK474CH94A Contact Us For Availability
C647
Capacitor,Ceramic,Chip LGE 0CK332CK56A Contact Us For Availability
C652
Capacitor,Ceramic,Chip LGE 0CC560CK41A Contact Us For Availability
C666
Capacitor,Ceramic,Ch LGE 0CK225DD66A Contact Us For Availability
C735
CAPACITOR,FIXED CERA LGE 0CK104CK56A Contact Us For Availability
C743
CAPACITOR,FIXED ELEC LGE 0CE226WF6DC Contact Us For Availability
C764
CAPACITOR,FIXED CERA LGE 0CK106EF56A Contact Us For Availability
C816
CAPACITOR,FIXED CERA LGE 0CK225DH94A Contact Us For Availability
C828
Capacitor,AL,Chip LGE 0CE107WK6DC Contact Us For Availability
C842
CAPACITOR,FIXED CERA LGE 0CK102CK56A Contact Us For Availability
C857
CAPACITOR,FIXED CERA LGE 0CK105CF94A Contact Us For Availability
C861
CAPACITOR,FIXED ELEC LGE 0CE227WJ6DC Contact Us For Availability
C865
CAPACITOR,FIXED CERA LGE 0CK224CF56A Contact Us For Availability
C868
CAPACITOR,FIXED ELEC LGE 0CE475WJ6DC Contact Us For Availability
C946
CAPACITOR,FIXED ELECTROLYTIC LGE 0CE107WF6DC Contact Us For Availability
C951
CAPACITOR,FIXED ELEC LGE 0CE477WF6DC Contact Us For Availability
C988
Capacitor,AL,Chip LGE 0CE106WH6DC Contact Us For Availability
C1016
CAPACITOR,FIXED ELEC LGE 0CE477EJ618 Contact Us For Availability
C1071
CAPACITOR,FIXED ELEC LGE 0CE227WF6DC Contact Us For Availability
D130
DIODE,RECTIFIERS LGE 0DRSE00038A Contact Us For Availability
D200
LED LGE 0DLAU0410AA Contact Us For Availability
D750
LED LGE 0DL233309AC Contact Us For Availability
D902
DIODE,SWITCHING LGE 0DS226009AA Contact Us For Availability
D905
Diode,Rectifier LGE 0DD200009AF Contact Us For Availability
IC302
IC,PERIPHERALS LGE 0IPRP00009A Contact Us For Availability
IC303
IC,STANDARD LOGIC LGE 0ISTL00031A Contact Us For Availability
IC400
IC,EEPROM LGE 0IMMRAL014D Contact Us For Availability
IC401
IC,Receiver LGE 0IPRP00701A Contact Us For Availability
IC600
IC,Voltage Detector LGE 0IFA752700A Contact Us For Availability
IC601
IC,Microprocessors LGE 0IPRP00689B Contact Us For Availability
IC602
IC,Multiplexer LGE 0IFA742530B Contact Us For Availability
IC603
IC,MEMORIES LGE 0IMMRAL025A Contact Us For Availability
IC800
IC,Bus Controller LGE 0IPRP00665A Contact Us For Availability
IC801
IC,Audio Amplifier LGE 0IPRP00700A Contact Us For Availability
IC802
IC,Data Controller LGE 0IPRP00743A Contact Us For Availability
IC902
IC,POWER MANAGEMENT LGE 0IPMG00027A Contact Us For Availability
IC903
IC,MICRO CONTROLLER LGE 0IMCRRH001A Contact Us For Availability
IC1001
IC,POWER MANAGEMENT LGE 0IPMGKE030A Contact Us For Availability
IC1003
IC,MICRO CONTROLLER LGE 0IMCRFA010A Contact Us For Availability
IC1008
IC,POWER MANAGEMENT LGE 0IPMGSG018D Contact Us For Availability
JK102
Jack,Complex LGE 6612J10025A Contact Us For Availability
JK105
Jack,RCA LGE 6612J10006M Contact Us For Availability
JK300
Jack,RCA LGE 6612J10003X Contact Us For Availability
JK302
JACK,PHONE LGE 6612F00099A Contact Us For Availability
JK303
Connector,DSUB LGE 6630G00003A Contact Us For Availability
JK304
Connector,DSUB LGE 6630G00001B Contact Us For Availability
JK800
Jack,RCA LGE 6612J10043A Contact Us For Availability
L119
Inductor,Multilayer, LGE 0LCML00020G Contact Us For Availability
L200
INDUCTOR,CHIP LGE 0LC1032101A Contact Us For Availability
L301
Filter,Bead LGE EAM30764201 Contact Us For Availability
L304
Filter,Bead LGE 6210TCE001E Contact Us For Availability
L804
INDUCTOR,CHIP LGE 0LCML00020C Contact Us For Availability
L808
COIL,ENERGY RECOVERY LGE 6140VR0008A Contact Us For Availability
L818
Filter,Bead LGE 6210TCE001P Contact Us For Availability
L1016
Filter,Bead LGE EAM30764101 Contact Us For Availability
P200
CONNECTOR (CIRC),WAF LGE 6602T20009J Contact Us For Availability
P201
CONNECTOR (CIRC),WAF LGE 6602T20009C Contact Us For Availability
P300
WAFER LGE 6602T20009E Contact Us For Availability
P301
CONNECTOR (CIRC),WAF LGE 6602T20008J Contact Us For Availability
P303
Connector,Wafer LGE 366-932B Contact Us For Availability
P603
Connector,Wafer LGE 6630V90116A Contact Us For Availability
P802
Connector,Wafer LGE 6602T25008B Contact Us For Availability
P900
WAFER LGE 6602T25008M Contact Us For Availability
P1001
WAFER LGE 6602T25008J Contact Us For Availability
Q402
TRANSISTOR LGE 0TR830009BA Contact Us For Availability
Q605
TR,Bipolar LGE 0TR102009AM Contact Us For Availability
Q606
TRANSISTOR LGE 0TR150400BA Contact Us For Availability
R101
Resistor,Chip LGE 0RH9101D622 Contact Us For Availability
R107
RESISTOR CHIP 3.3K 1/10W 5 D. LGE 0RH3301D622 Contact Us For Availability
R197
RESISTOR,METAL GLAZE LGE 0RJ2203D677 Contact Us For Availability
R202
Resistor,Chip LGE 0RH6800D622 Contact Us For Availability
R204
RESISTOR CHIP 6.8K 1/10W 5 D. LGE 0RH6801D622 Contact Us For Availability
R208
RESISTOR CHIP 3.9K 1/10W 5 D. LGE 0RH3901D622 Contact Us For Availability
R301
RESISTOR CHIP 220K 1/10W 5 D. LGE 0RH2203D622 Contact Us For Availability
R303
RESISTOR CHIP 470 1/10W 5 D.R LGE 0RH4700D622 Contact Us For Availability
R350
RESISTOR,METAL GLAZE LGE 0RJ2202D677 Contact Us For Availability
R425
RESISTOR,METAL GLAZE LGE 0RJ4990D477 Contact Us For Availability
R436
RESISTOR,METAL GLAZE LGE 0RJ0222D677 Contact Us For Availability
R509
RESISTOR,METAL GLAZE LGE 0RJ2200D677 Contact Us For Availability
R512
RESISTOR,METAL GLAZE LGE 0RJ0822D677 Contact Us For Availability
R519
RESISTOR,METAL GLAZE LGE 0RJ2700D677 Contact Us For Availability
R540
RESISTOR,METAL GLAZE LGE 0RJ7501D677 Contact Us For Availability
R632
RESISTOR,METAL GLAZE LGE 0RJ1802D677 Contact Us For Availability
R660
Resistor,Chip LGE 0RJ8201D677 Contact Us For Availability
R673
RESISTOR,METAL GLAZE LGE 0RJ6201D677 Contact Us For Availability
R704
Resistor,Chip LGE 0RJ6202D677 Contact Us For Availability
R705
Resistor,Chip LGE 0RJ2402D677 Contact Us For Availability
R708
RESISTOR,METAL GLAZE LGE 0RJ1501D677 Contact Us For Availability
R761
RESISTOR,METAL GLAZE LGE 0RJ1001D677 Contact Us For Availability
R803
Resistor,Chip LGE 0RJ1000D477 Contact Us For Availability
R822
RESISTOR,METAL GLAZE LGE 0RJ2001D677 Contact Us For Availability
R828
RESISTOR,METAL GLAZE LGE 0RJ4703D677 Contact Us For Availability
R847
RESISTOR,METAL GLAZE LGE 0RJ1003D677 Contact Us For Availability
R852
RESISTOR,METAL GLAZE LGE 0RJ4701D677 Contact Us For Availability
R905
Resistor,Chip LGE 0RJ2000D677 Contact Us For Availability
R1000
Resistor,Chip LGE 0RJ1201D677 Contact Us For Availability
R1001
RESISTOR,METAL GLAZE LGE 0RJ0752D677 Contact Us For Availability
R1004
RESISTOR,METAL GLAZE LGE 0RJ1002D677 Contact Us For Availability
SW104
SWITCH TACT LGE 140-313B Contact Us For Availability
TU1
Tuner,Analog LGE 6700MF0017C Contact Us For Availability
X600
Crystal LGE 6202VDT002P Contact Us For Availability
ZD1000
DIODE,ZENERS LGE 0DZKE00048A Contact Us For Availability
× ![]()
Login and Registration Form
