Model LG 26LC2D – Common Parts & Diagrams
Diagram 0
Diagram 1
Common parts from model LG 26LC2D
020
LCD,Module-TFT LGE 6304FAU020B Contact Us For Availability
030
Cover Assembly LGE 3809900134D Contact Us For Availability
040
Base Assembly LGE 3043900029H Contact Us For Availability
041
TILT SWIVEL ASSEMBLY LGE 3043900026D Contact Us For Availability
050
PCB Assembly LGE EBR32999901 Contact Us For Availability
060
Plate Assembly LGE 49519S0021G Contact Us For Availability
070
PWB(PCB) ASSEMBLY,SU LGE 68719STA37A Contact Us For Availability
080
SMPS,AC/DC LGE 6709900016C Contact Us For Availability
080
POWER SUPPLY ASSEMBL LGE 6709900016A Contact Us For Availability
090
Main Total Assembly LGE EBU32119801 Contact Us For Availability
100
Plate Assembly LGE 49519S0030J Contact Us For Availability
110
Speaker,Fullrange LGE EAB30827201 Contact Us For Availability
120
PCB Assembly LGE EBR31360201 Contact Us For Availability
130
Plate LGE 4950TKA041B Contact Us For Availability
140
Bracket Assembly LGE 4811900063A Contact Us For Availability
150
COVER LGE 35509K0197A Contact Us For Availability
A1
Manual LGE 38289U0527M Contact Us For Availability
A2
Remote Controller LGE 6710900010X Contact Us For Availability
A3
Power Cord LGE 6410TUW007A Contact Us For Availability
A21
Cover LGE 3550V00590A Contact Us For Availability
AC1
FILTER(CIRC),EMC LGE 6200J000151 Contact Us For Availability
AR3021
Resistor,Array LGE 0RJ1001C687 Contact Us For Availability
AR6007
Resistor,Chip LGE 0RJ0222C692 Contact Us For Availability
AR7004
Filter,Bead LGE EAM38769509 Contact Us For Availability
C1
Harness,Single LGE EAD30302101 Contact Us For Availability
C2
CONNECTOR ASSEMBLY LGE 6631T25019T Contact Us For Availability
C3
Harness,Single LGE 6631900012C Contact Us For Availability
C5
Cable,Assembly LGE 68509A0004U Contact Us For Availability
C6
CONNECTOR ASSEMBLY LGE 6631900010F Contact Us For Availability
C7
Harness,Single LGE 6631900049C Contact Us For Availability
C8
Cable,Assembly LGE EAD54642601 Contact Us For Availability
C9
CONNECTOR ASSEMBLY LGE 6631T25026C Contact Us For Availability
C10
CONNECTOR ASSEMBLY LGE 6631900048A Contact Us For Availability
C11
Harness,Single LGE 6631900050A Contact Us For Availability
C12
Harness,Single LGE 6631900018H Contact Us For Availability
C102
Capacitor,Ceramic,Chip LGE 0CH5101K416 Contact Us For Availability
C1012
CAPACITOR,FIXED CERA LGE 0CK105CD56A Contact Us For Availability
C1034
CAPACITOR,FIXED CERA LGE 0CK475CC94A Contact Us For Availability
C1059
Capacitor,Ceramic,Chip LGE 0CH2122K516 Contact Us For Availability
C2010
Capacitor,Ceramic,Ch LGE 0CK104BF56A Contact Us For Availability
C3066
Capacitor,Ceramic,Ch LGE 0CK106DC67A Contact Us For Availability
C4005
CAPACITOR,FIXED CERA LGE 0CK334CF56A Contact Us For Availability
C4008
CAPACITOR,FIXED CERA LGE 0CC270CK41A Contact Us For Availability
C4014
CAPACITOR,FIXED CERA LGE 0CC221CK41A Contact Us For Availability
C4047
Capacitor,AL,Chip LGE EAE30840201 Contact Us For Availability
C4063
Capacitor,AL,Chip LGE EAE30840401 Contact Us For Availability
C4064
Capacitor,AL,Chip LGE EAE34990901 Contact Us For Availability
C4083
Capacitor,AL,Chip LGE EAE30840301 Contact Us For Availability
C4085
CAPACITOR,FIXED ELEC LGE 0CE227WF6DC Contact Us For Availability
C4099
Capacitor,Ceramic,Chip LGE 0CK224CFG6A Contact Us For Availability
C4100
Capacitor,Ceramic,Chip LGE 0CK153CK51A Contact Us For Availability
C4101
Capacitor,Ceramic,Chip LGE 0CC561CK41A Contact Us For Availability
C4102
CAPACITOR,FIXED CERA LGE 0CK476FD67A Contact Us For Availability
C5002
CAPACITOR,FIXED CERA LGE 0CK103CK56A Contact Us For Availability
C5031
CAPACITOR,CHIP[AL. E LGE 0CH8226F691 Contact Us For Availability
C5033
CAPACITOR,FIXED ELEC LGE 0CE476WH6DC Contact Us For Availability
C5060
CAPACITOR,FIXED CERA LGE 0CK222CK56A Contact Us For Availability
C5079
CAPACITOR,CHIP[AL. E LGE 0CH8106F691 Contact Us For Availability
C5109
Capacitor,Ceramic,Chip LGE 0CH2474F566 Contact Us For Availability
C6005
CAPACITOR,FIXED ELECTROLYTIC LGE 0CE107WF6DC Contact Us For Availability
C7003
CAPACITOR,FIXED ELEC LGE 0CE226WF6DC Contact Us For Availability
C7021
CAPACITOR,FIXED CERA LGE 0CK225DH94A Contact Us For Availability
C7032
Capacitor,Ceramic,Chip LGE 0CK105DH56A Contact Us For Availability
C7038
Capacitor,Ceramic,Chip LGE 0CC470CK41A Contact Us For Availability
C7044
Capacitor,AL,Chip LGE 0CE106WH6DC Contact Us For Availability
C7045
Capacitor,AL,Chip LGE 0CE107WK6DC Contact Us For Availability
C7095
CAPACITOR,FIXED ELEC LGE 0CE106WFKDC Contact Us For Availability
C7096
Capacitor,Ceramic,Chip LGE 0CH5220K416 Contact Us For Availability
C7142
CAPACITOR,FIXED CERA LGE 0CK104CK56A Contact Us For Availability
C7154
Capacitor,Ceramic,Ch LGE 0CK474DK56A Contact Us For Availability
C7159
CAPACITOR,FIXED ELEC LGE 0CE227WJ6DC Contact Us For Availability
D4001
DIODE,RECTIFIERS LGE 0DRSE00038A Contact Us For Availability
D4006
LED LGE 0DL233309AC Contact Us For Availability
D4008
DIODE,SWITCHING LGE 0DS226009AA Contact Us For Availability
D4008
DIODE,SWITCHING LGE 0DSIH00018A Contact Us For Availability
D5015
DIODE,ZENERS LGE 0DZRM00178A Contact Us For Availability
D6001
DIODE,RECTIFIER LGE 0DR340009AA Contact Us For Availability
IC1001
IC,Data Controller LGE 0IPRP00702A Contact Us For Availability
IC2003
IC,DDR SDRAM LGE 0IMMRHY057E Contact Us For Availability
IC3001
IC,Analog Switch LGE EAN30267601 Contact Us For Availability
IC4001
IC,PERIPHERALS LGE 0IPRP00009A Contact Us For Availability
IC4001
IC,Tx/Rx LGE EAN39038801 Contact Us For Availability
IC4004
IC,KEC LGE 0IKE702900G Contact Us For Availability
IC4006
IC,PERIPHERALS LGE 0IPRPFA015B Contact Us For Availability
IC4007
IC,STANDARD LOGIC LGE 0ISTLPH026A Contact Us For Availability
IC4008
IC,LDO Voltage Regul LGE 0IPMGS1006B Contact Us For Availability
IC4011
IC,MICRO CONTROLLER LGE 0IMCRRH001A Contact Us For Availability
IC4012
IC,MICRO CONTROLLER LGE 0IMCRAL021A Contact Us For Availability
IC4014
IC,MICRO CONTROLLER LGE 0IMCRAL006A Contact Us For Availability
IC4016
IC,Voltage Regulator LGE EAN32662801 Contact Us For Availability
IC4016
IC,MICRO CONTROLLER LGE 0IMCRFA010A Contact Us For Availability
IC4017
IC,DC,DC Converter LGE EAN31513601 Contact Us For Availability
IC5001
IC,Analog Switch LGE EAN30744301 Contact Us For Availability
IC5002
IC,Analog Switch LGE EAN30744401 Contact Us For Availability
IC5003
IC,SONY LGE 0ISO206900A Contact Us For Availability
IC5004
IC,PERIPHERALS LGE 0IPRPCI016A Contact Us For Availability
IC6001
IC,POWER MANAGEMENT LGE 0IPMG00063A Contact Us For Availability
IC6004
IC,MICRO CONTROLLER LGE 0IMCRTH002A Contact Us For Availability
IC7001
IC,CRYSTAL SEMICONDUCTOR LGE 0ICB533100A Contact Us For Availability
IC7004
IC,PERIPHERALS LGE 0IPRP00696A Contact Us For Availability
IC7004
IC,A/D Converter LGE 0IPRP00696D Contact Us For Availability
IC7005
IC,MEMORIES LGE 0IMMRCS012B Contact Us For Availability
IC7010
IC,EEPROM LGE 0IMMRAL014D Contact Us For Availability
IC7016
IC,Receiver LGE 0IPRP00623A Contact Us For Availability
IC7017
IC,Audio Amplifier LGE 0IPRP00700A Contact Us For Availability
J4002
Jack,Complex LGE 6612J10024A Contact Us For Availability
J4003
JACK,PHONE LGE 6612F00099A Contact Us For Availability
J5007
Jack,RCA LGE 6612J10006K Contact Us For Availability
JK100
Jack,Fiber Optic LGE EAG32151101 Contact Us For Availability
JK101
JACK,RCA LGE 6612J10033A Contact Us For Availability
L2001
Filter,Bead LGE EAM38769502 Contact Us For Availability
L3002
Inductor,Wire Wound, LGE EAP37991401 Contact Us For Availability
L4007
FILTER(CIRC),EMC LGE 6200J000123 Contact Us For Availability
L4011
FILTER(CIRC),EMC LGE 0LCML00003B Contact Us For Availability
L4021
Filter,Bead LGE 6210TCE001E Contact Us For Availability
L4021
Filter,Bead LGE EAM42641602 Contact Us For Availability
L4022
COIL,CHOKE LGE 6140TBZ047B Contact Us For Availability
L5003
Filter,Bead LGE EAM38769501 Contact Us For Availability
L6001
COIL,ENERGY RECOVERY LGE 6140VR0008B Contact Us For Availability
L7020
INDUCTOR,CHIP LGE 0LCML00020B Contact Us For Availability
L7020
INDUCTOR,CHIP LGE 0LC2000005J Contact Us For Availability
L7029
COIL,ENERGY RECOVERY LGE 6140VR0008A Contact Us For Availability
L7038
Filter,Bead LGE EAM30764101 Contact Us For Availability
L7044
Filter,Bead LGE EAM38769505 Contact Us For Availability
L7044
FILTER(CIRC),EMC LGE 6210TCE001S Contact Us For Availability
LED1
LED LGE 0DL200000CA Contact Us For Availability
LV1
Harness,Single LGE 6631900060A Contact Us For Availability
LV1
Harness,Single LGE 6631900060B Contact Us For Availability
P102
CONNECTOR (CIRC),WAF LGE 6602T20009C Contact Us For Availability
P4003
WAFER LGE 6602T25008J Contact Us For Availability
P4004
WAFER LGE 6602T25008M Contact Us For Availability
P4005
CONNECTOR (CIRC),WAF LGE 6602T25008L Contact Us For Availability
P6001
Connector,Wafer LGE 6630V90116A Contact Us For Availability
P7004
CONNECTOR (CIRC),D-S LGE 6630G70016A Contact Us For Availability
P7007
Jack,DIN LGE 6612B00015C Contact Us For Availability
P7010
Connector,Wafer LGE 6602T25008B Contact Us For Availability
P7011
CONNECTOR (CIRC),WAF LGE 6602T20009J Contact Us For Availability
Q5005
TRANSISTOR LGE 0TR150400BA Contact Us For Availability
Q5017
TRANSISTOR,BIPOLARS LGE 0TRIY80001A Contact Us For Availability
Q7002
TRANSISTOR,BIPOLARS LGE 0TRIH80003A Contact Us For Availability
R102
RESISTOR CHIP 3.3K 1/10W 5 D. LGE 0RH3301D622 Contact Us For Availability
R104
RESISTOR CHIP 200 1/10W 5 TA C LGE 0RH2000D622 Contact Us For Availability
R106
RESISTOR CHIP 1.2K 1/10W 5 D. LGE 0RH1201D622 Contact Us For Availability
R1006
RESISTOR,METAL GLAZE LGE 0RJ2000D477 Contact Us For Availability
R1008
RESISTOR,METAL GLAZE LGE 0RJ0102D677 Contact Us For Availability
R1021
Resistor,Chip LGE 0RJ0562D477 Contact Us For Availability
R1038
Resistor,Chip LGE 0RJ0000C678 Contact Us For Availability
R1044
Resistor,Chip LGE 0RH1504D622 Contact Us For Availability
R1046
RESISTOR,METAL GLAZE LGE 0RJ4990D477 Contact Us For Availability
R1085
Resistor,Chip LGE 0RJ0271D677 Contact Us For Availability
R1132
Resistor,Chip LGE 0RJ0752C678 Contact Us For Availability
R1141
RESISTOR,METAL GLAZE LGE 0RJ0392D677 Contact Us For Availability
R1159
Resistor,Chip LGE 0RJ3601D677 Contact Us For Availability
R3006
RESISTOR,METAL GLAZE LGE 0RJ2701C678 Contact Us For Availability
R3015
Resistor,Chip LGE 0RJ1501D477 Contact Us For Availability
R3017
RESISTOR,METAL GLAZE LGE 0RJ3000D677 Contact Us For Availability
R4048
RESISTOR,METAL GLAZE LGE 0RJ4300D677 Contact Us For Availability
R4084
RESISTOR,METAL GLAZE LGE 0RJ4701D677 Contact Us For Availability
R4137
Resistor,Chip LGE 0RJ6802D677 Contact Us For Availability
R4184
RESISTOR,METAL GLAZE LGE 0RJ1001D477 Contact Us For Availability
R5035
Resistor,Chip LGE 0RJ7500D677 Contact Us For Availability
R5055
RESISTOR,METAL GLAZE LGE 0RJ2200D677 Contact Us For Availability
R5068
Resistor,Chip LGE 0RJ2201D677 Contact Us For Availability
R5069
RESISTOR,METAL GLAZE LGE 0RJ1003D677 Contact Us For Availability
R5101
Resistor,Chip LGE 0RJ6801D677 Contact Us For Availability
R5121
RESISTOR,METAL GLAZE LGE 0RJ0752D677 Contact Us For Availability
R5122
RESISTOR,METAL GLAZE LGE 0RJ4703D677 Contact Us For Availability
R5128
RESISTOR,METAL GLAZE LGE 0RJ2701D677 Contact Us For Availability
R6004
RESISTOR,METAL GLAZE LGE 0RJ2202D677 Contact Us For Availability
R6005
RESISTOR,METAL GLAZE LGE 0RJ1202D677 Contact Us For Availability
R7006
RESISTOR,METAL GLAZE LGE 0RJ1001D677 Contact Us For Availability
R7008
RESISTOR,METAL GLAZE LGE 0RJ2700D677 Contact Us For Availability
R7019
Resistor,Chip LGE 0RJ4701C678 Contact Us For Availability
R7030
Resistor,Chip LGE 0RJ1002C678 Contact Us For Availability
R7043
RESISTOR,METAL GLAZE LGE 0RJ3900D677 Contact Us For Availability
R7057
Resistor,Chip LGE 0RJ0332C678 Contact Us For Availability
R7058
RESISTOR,METAL GLAZE LGE 0RJ0682D677 Contact Us For Availability
R7071
RESISTOR,METAL GLAZE LGE 0RJ1502D677 Contact Us For Availability
R7105
Resistor,Chip LGE 0RJ0222C678 Contact Us For Availability
R7201
RESISTOR,METAL GLAZE LGE 0RJ0222D677 Contact Us For Availability
R7219
Resistor,Chip LGE 0RJ0182D677 Contact Us For Availability
R7226
Resistor,Chip LGE 0RJ1001C678 Contact Us For Availability
R7243
RESISTOR,METAL GLAZE LGE 0RJ1002D677 Contact Us For Availability
X3001
Crystal LGE 6212AA2600B Contact Us For Availability
X3001
Crystal LGE 6212AA2600A Contact Us For Availability
X7001
CRYSTAL LGE 6202TST001A Contact Us For Availability
ZD1001
Diode,Zener LGE 0DZDI00078A Contact Us For Availability
ZD7004
DIODE,ZENERS LGE 0DZRM00218A Contact Us For Availability
× ![]()
Login and Registration Form
