Model Kenmore 253.14552102 FREEZER – Common Parts & Diagrams

*
Insulation-door, fiberglass, (bulk)
Insulation-door, fiberglass, (bulk) WCI 5303917276 Contact Us For Availability
View on Model
1
Catch-lock, white
Catch-lock, white WCI 216909800 Contact Us For Availability
View on Model
1A
Support, lock catch clip
Support, lock catch clip WCI 216818900 Contact Us For Availability
View on Model
2
Adapter, drain hose
Adapter, drain hose WCI 216269500 Contact Us For Availability
View on Model
3
Plug, drain, interior
Plug, drain, interior WCI 216502600 Contact Us For Availability
View on Model
4
Plug, drain, exterior
Plug, drain, exterior WCI 297013600 Contact Us For Availability
View on Model
5#
Harness-main
Harness-main WCI 216987300 Contact Us For Availability
View on Model
10
Plug button, 1/4", white
Plug button, 1/4", white WCI 216923001 No Longer Available
View on Model
11
Lid, white
Lid, white WCI 216129931 Contact Us For Availability
View on Model
22
Clip, compressor mtg, SPRING
Clip, compressor mtg, SPRING WCI 216056400 Contact Us For Availability
View on Model
28
Support, compressor
Support, compressor WCI 5303212615 Contact Us For Availability
View on Model
40
Fastener, .330 dia stud, handle, (2)
Fastener, .330 dia stud, handle, (2) WCI 216922700 Contact Us For Availability
View on Model
42
Washer, flat, 1"OD x 0.531"ID
Washer, flat, 1"OD x 0.531"ID WCI 216232700 Contact Us For Availability
View on Model
59
Basket, upper, (2)
Basket, upper, (2) WCI 216916200 Contact Us For Availability
View on Model
75
Panel, access, white
Panel, access, white WCI 216034301 Contact Us For Availability
View on Model
94
Lens, frost indicator, blue
Lens, frost indicator, blue WCI 216140400 Contact Us For Availability
View on Model
100
Track-basket
Track-basket WCI 216995201 Contact Us For Availability
View on Model
150
Support, track-basket
Support, track-basket WCI 216997400 Contact Us For Availability
View on Model
